A 70-year-old male patient with a history of colorectal cancer presented with nausea, abdominal pain and jaundice. Imaging studies indicated diffuse peritoneal spread and lung metastases as well as intrahepatic biliary dilation. Laboratory assessment indicated marked cholestasis (bilirubin 6.8 mg/dL, alkaline phosphatase 1,019 U/L). Conventional endoscopic retrograde cholangiopancreatography (ERCP) proved impossible due to a high-grade proximal duodenal bulb stricture (Fig. 1A) estimated at 20 mm axial length on fluoroscopy (not shown). Therefore, the patient first underwent gastroduodenal stenting using a 60x20-mm uncovered self-expanding metal stent (SEMS; Taewoong Medical; Fig. 1B). In order to facilitate timely through-the-stent ERCP (TTS-ERCP), stent fixation using the newly marketed dedicated anchoring device stentfixOTSC® (Ovesco Endoscopy) was used (Fig. 1C,D). As a derivative of the conventional over-the-scope clip (OTSC) platform, the device design is different in its brackets being bowed to the outside, and indentations in the application cap, both instrumental for better stent engagement [1]. Albeit careful attempts at same-session duodenoscope passage failed, the patient underwent successful TTS-ERCP the following day after full stent expansion with the papilla located more distally. Nonetheless, biliary access proved difficult but could be achieved by double guidewire cannulation with subsequent prophylactic pancreatic duct stenting. On the cholangiogram, an estimated 45-mm long bile duct stricture emerged which was provided with an 80x10-mm fully covered SEMS placed above the papilla (“
Figure 1 (A) Endoscopic visualization of the high-grade proximal duodenal bulb stricture with the cannula and guidewire already placed for subsequent gastroduodenal stenting. (B) The deployed stentfixOTSC® engaged to the proximal end of a 60x20-mm uncovered gastroduodenal self-expanding metal stent (SEMS). (C) Fluoroscopic demonstration of the newly placed SEMS with the stentfixOTSC® tightly attached (note brackets being bowed to the outside). (D) Successful through-the-stent endoscopic retrograde cholangiopancreatography (TTS-ERCP) with difficult biliary access (double guidewire technique) and a long stricture in the, bile duct provided with an 80x10-mm fully covered SEMS
Stent anchoring is about to emerge as a new standard in gastrointestinal stent treatment, at least so when using covered stent technology. By contrast, although uncovered stents are in general less prone to stent migration, however, in certain situations where mechanical forces may be high in newly deployed stents, such as in TTS-ERCP procedures, stent anchoring by the newly marketed stentfixOTSC® system may be instrumental to enhance procedural safety [2,3].
