Ultra-magnifying endocytoscopy (EC) enabling the direct observation of cells and nuclei was developed recently [1,2], but there have been few reports regarding the usefulness of EC for malignant lymphoma (ML). Therefore, we applied EC for the diagnosis of ML.
An 80-year-old man was referred to our hospital because of bloody stool. Colonoscopy using EC (CF-H290EC, Olympus, Tokyo) was performed, and an elevated lesion with sparse depressed area was identified at the terminal ileum (Fig. 1A). Chromoendoscopy with magnification revealed an elevated area that was composed of villous mucosa similar to normal ileum (Fig. 1B), whereas the depressed area appeared as non-structural mucosa (Fig. 1B,C). At this stage, since differential diagnosis was difficult, we performed EC using methylene blue. The villous mucosa of the elevated area was also shown as normal structure with non-neoplastic cells by EC. In contrast, the surface structure of the depressed area was irregular, and dense nuclei with diverse sizes were seen (Fig. 1D). These findings led us to suspect ML and we obtained target biopsies from both areas. In the elevated area, the surface was histologically covered by non-neoplasia (Fig. 2A), whereas in the depressed area (Fig. 2B) malignant lymphocytes that tested positive for CD20 (Fig. 2C) and cyclin D1 (Fig. 2D) were exposed to the surface. These malignant lymphocytes were also positive for CD5, and negative for CD10, which indicated mantle cell lymphoma.
Figure 1 Endoscopic findings of malignant lymphoma located at the terminal ileum. (A) There was an elevated lesion with depression at the terminal ileum. (B) Indigo carmine staining showed the elevated area composed of villous structure. (C) After methylene blue staining, the depressed area (red square of Fig. 1B) was shown as non-structural mucosa. (D) Ultra-magnifying endocytoscopy at the depressed area (yellow square of Fig. 1C) showed irregular nuclei
Figure 2 Histological findings of target biopsies. Hematoxylin and eosin stain, 40x (A,B). Immunohistochemistry CD20 200x (C), Cyclin D1 200x (D). (A) Target biopsy from elevated area. Superficial layer was composed of non-neoplastic mucosa. Under the non-neoplastic mucosa, lymphocytes were shown. (B) Target biopsy from depressed area. From the superficial layer, malignant lymphocytes were shown. There were few mucosal structures. (C,D) The lymphocytes exposed to the surface tested positive for CD20 and cyclin D1, which indicated mantle cell lymphoma
We obtained clear EC images of ML by target biopsies. However, we were able to observe the cells and nuclei of the extremely superficial layers by EC. Thus, to carefully observe the area where ML is exposed is essential.
Video legend Endocytoscopic findings with methylene blue staining, also showing histological appearance (see online version)
